Khoom Taw Qhia
Tsis tshua muaj kub sib tsoo tshuab rau cov txuj lom yog txheej txheem ntawm kev sib tsoo cov txuj lom ntawm qhov kub thiab txias (feem ntau yog los ntawm cov kua nitrogen) qis dua xoom degrees Celsius.
Cov thev naus laus zis no tuaj yeem tiv thaiv cov cua sov uas tsim los ntawm kev sib tsoo tsoos los ntawm kev puas tsuaj rau cov roj uas tsis muaj zog uas muab cov txuj lom rau lawv cov aroma thiab tsw, yog li tsim cov khoom kawg uas yog khaus thiab ze rau qhov qub tsw.
|
Qauv |
WF-180 |
WF-20B |
WF-30B |
WF-40B |
WF-50B |
WF-60B |
|
Hwj chim |
2.2 KW TSI |
4 KW |
5.5 KW TSI |
11 kWm |
15 KW |
22 kwv |
|
Qhov hluav taws xob |
220V-440V |
|||||
|
Muaj peev xwm |
10-50kg / h |
60-150kg / h |
100-300kg / h |
160-800kg / h |
300-1000kg / h |
500-1500kg / h |
|
Maxi Pub Loj |
6mm ib |
6mm ib |
10 hli |
12 hli |
15 hli |
15 hli |
|
Qhov kawg loj |
10-120 mesh |
20-120 mesh |
20-120 mesh |
20-120 mesh |
20-120 mesh |
20-120 mesh |
|
Qhov ntev |
500 * 580 * 1000 hli |
550 * 650 * 1200 hli |
600 * 750 * 1350 hli |
700 * 850 * 1550 hli |
800 * 870 * 1780 hli |
900 * 900 * 1900 hli |
|
Qhov hnyav |
100 kg |
150 kg |
210kg ua |
350kg ua |
500 kg |
7 60kg |
Qhov teeb meem ntawm tsoos tsoos
Kev cuam tshuam ntawm tshav kub ntawm cov roj tsis hloov pauv
Thaum tshav kub kub yog tus yeeb ncuab tseem ceeb ntawm cov yam ntxwv ntawm cov txuj lom. Feem ntau ntawm cov aroma thiab tsw nyob rau hauv cov txuj lom yog muaj nyob rau hauv lawv volatile roj, uas yog heev rhiab heev thiab yooj yim evaporate thaum rhuab.
Aroma thiab tsw degradation
Raws li cov roj no tau poob thaum lub sij hawm siab -kub sib tsoo txheej txheem, cov hmoov nplej uas ua rau muaj kev ua tau zoo thiab tsis tshua muaj qhov nyuaj piv rau nws daim ntawv qub qub.
Kev sib tsoo tsis sib xws
Cov txuj lom uas muaj roj ntau lossis cov ntsiab lus noo noo yuav ua tuab thaum cua sov, ua rau muaj kev sib tsoo tsis sib xws thiab cov tsos ntawm qhov loj, qhov tsis zoo.
Yuav ua li cas Tsawg kub sib tsoo tshuab rau txuj lom muab superior zoo
Cov nyhuv ntawm qhov kub tsis tshua muaj siab
Cov txuj lom tau khov sai sai siv cov kua nitrogen, txias kom qis dua xoom degrees. Qhov no ua rau cov txuj lom heev nkig thiab iav -zoo li, tshem tawm cov nplaum.
Maximize qhov khaws cia ntawm cov tshuaj volatile
Raws li tag nrho cov txheej txheem tshwm sim nyob rau hauv ib qho inert, ultra{0}} ib puag ncig txias, cov roj tsis hloov pauv tuaj yeem ua tsis tiav. Lub aroma thiab tsw yog kaw nyob rau hauv cov txuj lom hmoov thiab tsis txhob khiav mus rau saum huab cua.
Ntau zoo thiab sib xws granularity
Lub brittleness ntawm cov txuj lom khov ua rau lawv nyob rau hauv cov hmoov zoo thiab tsis tshua muaj neeg sib xws. Tsis tshua muaj kub sib tsoo tshuab rau cov txuj lom kom ntseeg tau tias txawm faib cov tsw thaum ntxiv rau cov zaub mov thiab ua rau muaj kev ntxhib los mos.
daim ntawv thov kev lag luam
Hluav taws xob tswj txee (Siemens PLC tswj vaj huam sib luag tuaj yeem hloov tau)
Pneumatic conveying siv
Cyclone separator hopper
Pulse plua plav tshem tawm cov cuab yeej
Daim ntawv thov Case
