Khoom taw qhia
Daim ntawv thov ntawm Pharmaceutical spray Dryery hauv kev lag luam kws tshuaj suav nrog, tab sis tsis txwv rau, kev npaj cov tshuaj micronisation systems (xws li microspheres thiab microcapsules), kev txhim kho cov tshuaj solubility thiab bioavailability, kev npaj ntawm kev tswj kev tso tawm formulations, thiab kev txhim kho lub cev lub cev ntawm cov tshuaj. cov tshuaj, xws li optimization ntawm functionality thiab stability ntawm cov tshuaj hmoov los ntawm kev tswj crystallisation thaum lub sij hawm cov tshuaj tsuag kom qhuav. Tsis tas li ntawd, tshuab ziab khaub ncaws yog siv los npaj cov khoom siv biotechnological xws li cov proteins, enzymes, amino acids thiab polysaccharides.
Pharmaceutical spray Dryer yog ntau yam thiab hloov kho thev naus laus zis hauv kev lag luam kws tshuaj uas muaj ntau yam kev siv rau kev txhim kho cov khoom siv tshuaj, suav nrog kev txhim kho ntawm solubility thiab bioavailability, kev npaj ntawm kev tswj-tso formulations, thiab kev txhim kho cov khoom ntawm lub cev. ntawm tshuaj. Raws li cov thev naus laus zis tau nkag siab zoo dua thiab nce qib, nws xav tias yav tom ntej cov ntawv thov hauv kev lag luam kws tshuaj yuav muaj ntau dua thiab muaj txiaj ntsig.
Khoom specification
|
Inlet kub |
140 degree ~ 350 degree tsis siv neeg tswj |
||||
|
Qhov hluav taws xob kub |
80 degree ~ 90 degree |
||||
|
Max.evaporated tus nqi ntawm noo noo (kg / h) |
5 |
5025 |
50 |
150 |
200-5000 |
|
Tsav tsheb daim ntawv ntawm centrifugai nozzie |
Compressed airdrive |
Mechanical tsav |
|||
|
Kev hloov pauv (rpm) |
25000 |
18000 |
18000 |
15000 |
8000~15000 |
|
Txoj kab uas hla ntawm atomizing disk (mm) |
50 |
120 |
120 |
150 |
180~240 |
|
Thaum tshav kub kub |
Hluav taws xob |
Sleam / Hluav taws xob |
Sleam/Electricity/Oilfuel/Hotaitfurnace |
||
|
Max.power ntawm hluav taws xob rhaub (kw) |
9 |
36 |
72 |
99 |
|
|
Overall dimensions (LWH) (m) |
1.8x0.93x2.2 |
3x2.7x4.26 |
3.5x3.5x4.8 |
5.5x4x7 |
Qhia rau nws raws li kev ua tau zoo |
|
Rov qab tus nqi ntawm cov hmoov qhuav (%) |
Ntau dua lossis sib npaug li 95 |
||||
Qhov zoo ntawm cov tshuaj tsuag kom qhuav rau kev siv tshuaj
1. Versatility: Pharmaceutical spray Dryer muaj peev xwm tuav tau ntau yam ntawm cov tshuaj formulations, suav nrog biologics thiab qhuav hmoov rau kev tswj tsis yog qhov ncauj.
2. Txhim kho cov tshuaj solubility thiab bioavailability: Txau kom qhuav tso cai rau kev npaj cov tshuaj me me, xws li microspheres thiab microcapsules, uas tuaj yeem txhim kho cov tshuaj solubility thiab bioavailability.
3. Cov txheej txheem tswj kev tso tawm: Cov tshuaj tsuag kom qhuav tuaj yeem siv los npaj cov tshuaj uas muaj kev tswj hwm kev tso tawm, uas yog ib qho tseem ceeb rau kev txhim kho cov tshuaj zoo thiab txo cov kev mob tshwm sim.
4. Txhim kho kev tsim khoom thiab cov khoom zoo: Daim ntawv thov ntawm cov tshuab ziab khaub ncaws tuaj yeem pab txhim kho kev tsim khoom thiab cov khoom zoo. Piv txwv li, los ntawm kev siv pre-set spraying tsis, yields zoo thiab zoo ib yam particle loj distributions yuav ua tau tiav nyob rau hauv thaum ntxov theem ntawm txoj kev loj hlob.
5. Ua kom yooj yim rau kev txhim kho kev tsim khoom tas mus li: Raws li kev lag luam kev lag luam hloov mus rau kev tsim khoom tas mus li, kev siv cov tshuaj tsuag kom qhuav raws li cov kauj ruam tseem ceeb hauv kev tsim me me, kev tsim khoom tas mus li qhib qhov tshiab muaj peev xwm txo nqi, nce kev yooj yim thiab cov khoom zoo.
6. Haum rau cov ntaub ntawv kub-rhiab: Piv rau lwm cov txheej txheem ziab, cov tshuaj tsuag kom qhuav yog maj mam thiab tsim nyog rau kev kho cov ntaub ntawv kub-rhiab.
